BodyGuardian™ remote cardiac monitors technical specs

Technical Specifications

​Characteristics​ BodyGuardian MINI SLBodyGuardian MINI EL
Dimensions​48 x 29 x 12 mm​59 x 30 x 13 mm​
Weight​18 grams​22 grams​
Operating temp​+0°C to +45°C​​ +0°C to +45°C​
Memory capacity​4.0 GB (30+ days of monitoring data)​4.0 GB (30+ days of monitoring data)​
Bluetooth​Yes​Yes​
ECG​
Sampling rate​125/250/500/1000 Hz (24 bits)
Channels​Single or Multiple (3 leads) ​
Input dynamic range​[-400, 400] mV​
Input offset dynamic​[-400, 400] mV​

Want more information?

Connect with us to learn more about the BodyGuardian MINI and MINI PLUS remote cardiac monitors.
