Get to know the BodyGuardian MINI PLUS, a user-friendly remote cardiac monitor that lets patients go about their daily lives while giving clinicians the high-quality data and integration solutions they need to get to an accurate diagnosis.
Integrate BodyGuardian cardiac monitors into your practice.
Clinical benefits
Designed with your practice and patients in mind
Full disclosure cardiac monitoring
Near real-time, beat-to-beat data for faster clinical decision making when it matters most
Data integration
Efficient, customizable integration solutions for a variety of platforms and workflows
Pediatrics approved
FDA cleared for adults and pediatric patients above 10kg (22lbs)
Long battery life
The fully rechargeable battery lasts up to 7 days in MCT mode
Single and multi-channel
Offers flexibility for specific vector views and certain patient populations
High-quality P-wave tracings
Vertical placement provides clear visibility into the P, QRS, and T wave phases of beats, enhancing arrhythmia detection
Patient comfort and compliance
Fully waterproof and submersible with multiple adhesive and placement options so patients can live life uninterrupted
Learn more about BodyGuardian
The cardiac algorithm with deep learning built in
The BodyGuardian MINI PLUS is powered by BeatLogic™, a cloud-based artificial intelligence (AI) platform that incorporates deep learning for superior ECG interpretation and faster clinical decision making.
The complete beat-to-beat story at your fingertips
The ECG Insight™ cloud-based system is the only solution for complete access to all ECG data for MCT and Holter studies.
See all rhythms in near real-time while the patient is wearing the monitor
Improve patient compliance and enable timely follow-up care
Request up to 10 minutes of data while specifying start time and duration
Generate a PDF report to integrate into your EMR system
Patient benefits
Created for patient comfort and compliance
Easy to place and reposition
No skin abrasion or alcohol required for application, multiple placement options, repositionable
Waterproof and showerproof
Truly waterproof and fully submersible MCT
An adhesive for all skin types
Active wear strip, sensitive skin strip, bridge, and lead wire options with single or multi-channel detection
Staying power
The fully rechargeable battery lasts up to 7 days in MCT mode
“I'm really happy that I wore the MINI PLUS. With a Holter monitor, I would have needed to wait for the study to finish, send the device back to the company, and wait for them to send a report to my doctor. In all that time, I would have had episodes where my heart stopped. Who knows what would have happened.”
Barbara, BodyGuardian MINI PLUS (MCT) patient
Resources for your patients
Explore a variety of educational materials designed to help patients complete the prescribed BodyGuardian MINI Plus monitoring period, including patient manuals, instructional videos, FAQs, and more.
| Characteristics | ||
|---|---|---|
| Dimensions | MINI EL: 59 x 30 x 13 mm, MINI: 48 x 29 x 12 mm | |
| Weight | MINI EL: 22 grams, MINI: 18 grams | |
| Ingress protection rating | IP67 | |
| Operating temperature | +0°C to +45°C | |
| Operating humidity | Relative humidity range of 15% to 90%, non-condensing | |
| Storage temperature | (Based on battery specifications): 1-month storage: -20°C to +60°C / 3-month storage: -20°C to +45 °C / 12-month storage: -20°C to +25°C | |
| Battery charger power requirement | 110-240V, 50-60Hz | |
| Battery capacity | 450 mAh | |
| Battery characteristics | 3.7 V Rechargeable Li-ion battery | |
| Memory capacity | 4.0 GB (30+ days of monitoring data) | |
| Bluetooth | Yes | |
| ECG | ||
| Sampling rate | 125/250/500/1000 Hz | |
| Sampling rate | 24 bits | |
| Channels | Single or Multiple (3 leads) | |
| Input Dynamic range | [-400, 400] mV | |
| Input Offset dynamic | [-400, 400] mV | |
| 3D accelerometer | ||
| Sample rate | 25/100 Hz | |
| Digital resolution | 12 bit |
510(k) clearance information
BodyGuardian MINI PLUS has received 510(k) clearance - K182030 and CE mark for pediatric and adult patients.
